NEW FLOW Pressure Switch Explosion Proof Type

http://www.new-flow.com

கடைசியாக புதுப்பிக்கப்பட்டது

விலை:

R.F.Q

The New-Flow PS2000X, an explosion proof pressure switch, is designed to be used in control systems, PS2000X has high set point repeatability and narrow dead band features. A variety of range selections are available upon request. Easily adjusted to the set point, and no special tools needed.

Share Product:

விவரம்

  • Switch Data : One SPDT & two SPDT Mircoswitch 15 apms 125/250VAC, DC 125V 0.4A, DC30V 3A
  • Gold Contact Microswitch 1A 125/250VAC
  • Housing : Die cast aluminium alloy with paint
  • Conduit Connection : Female ¾", ½"NPT, M20 x P1.5 available
  • Pressure Element : welded type diaphragm
  • Process Material : Wetted parts all in SS316
  • Process Coneection : Female ½" or ¼" NPT, BSP, PT; and M20 x P1.5 thread available
  • Repeatability : ±1% of full scale

விவரக்குறிப்பு

திறவுச்சொல்
பிராண்ட்
தோற்றம்TW
